Managed Ethernet Switch Redundancy Protocol (UI 2.0) Turbo Ring
2-7
Ring: Turbo Ring Status
Shows Healthy if the ring is operating normally, and shows Break if the ring’s backup link is active.
Ring: 1st Port Status / Ring: 2nd Port Status
The “Ports Status” indicators show Forwarding for normal transmission, Blocking if this port is connected to
a backup path and the path is blocked, and Link down if there is no connection.
Ring Coupling: Role
Indicates whether or not this switch is assigned as coupler.
Ring Coupling: Coupling Port Status
Ring Coupling: Coupling Control Port Status
The “Ports Status” indicators show Forwarding for normal transmission, Blocking if this port is connected to
a backup path and the path is blocked, and Link down if there is no connection.
Explanation of “Settings” Items
Set as Master
Setting Description Factory Default
Enabled
Select this switch as Master
Not checked
Disabled Do not select this switch as Master
Redundant Ports
Setting Description Factory Default
1st Port Select any port of the switch to be one of the redundant ports.
Port G2
2nd Port Select any port of the switch to be one of the redundant ports.
Port G3
Ring Coupling: Enable
Setting Description Factory Default
Enable Select this switch as Coupler Not checked
Disable Do not select this switch as Coupler
Ring Coupling: Coupling Port
Setting Description Factory Default
Coupling Port Select any port of this switch to be the coupling port Port G1
Ring Coupling: Coupling Control Port
Setting Description Factory Default
Coupling Control Port Select any port of this switch to be the coupling control port Port 7
