Managed Ethernet Switch Redundancy Protocol (UI 2.0) V-ON
5-4
Configure Multicast Fast Forward
In an IGMP Snooping setting, Multicast Fast Forwarding Mode is one function of V-ON technology that should
be enabled in layer 2 and layer 3 switches.
Enable Multicast Fast Forwarding Mode
Setting Description Factory Default
Enable/Disable
Select the Enable Multicast Fast Forwarding Mode checkbox to
achieve fast multicast forwarding path re-learning while the
ring redundant network is down.
Note: Turbo Ring V2 or Turbo Chain must be enabled.
Disable
