Managed Ethernet Switch Redundancy Protocol (UI 2.0) STP/RSTP/MSTP
5-10
Max. Age (sec.)
Setting Description Factory Default
Numerical value input by user
(6-40)
If this device is not the root, and it has not received a
hello message from the root in an amount of time
equal to “Max. Age,” then this device will reconfigure
itself as a root. Once two or more devices on the
network are recognized as a root, the devices will
renegotiate to set up a new Spanning Tree topology.
20
Revision Level
Setting Description Factory Default
Numerical value input by user
(0-65535)
The MSTP revision level is the revision number of the
configuration. All EDS switches in an MSTP region
must be configured with the same revision level.
0
Region Name
Setting Description Factory Default
Character string The region name helps define the logical boundary of
the network. All EDS switc
hes in an MSTP region must
be configured with the same name.
MSTP
Configuration confirm
Setting Description Factory Default
Enable/Disable Clicking “Apply” button will only save the MSTP
settings temporarily; you can select to enable this
configuration to activate the MSTP settings during the
operation.
Disabled
Explanation of “Instance Settings” Items
Instance ID
Setting Description Factory Default
Numerical value selected by
user
Within each MST region, the MSTP maintains multiple
spanning-tree instances. A common and internal
spanning tree (CIST) is a collection of the following:
ISTs in each MST region, and the common spanning
tree (CST) that interconnects the MST regions, and a
single spanning tree. All other MST instances are
numbered from 1 to 15.
Cist
Vlan Mapping
Setting Description Factory Default
Numerical value input by user
(1-4094)
Configure which VLAN ID is mapped to the multiple
spanning-tree instances.
None
Bridge priority
Setting Description Factory Default
Numerical value selected by
user
Increase this device’s bridge priority by selecting a
lower number. A device with a higher bridge priority
has a greater chance of being established as the root
of the Spanning Tree topology.
32768
