Managed Ethernet Switch Redundancy Protocol (UI 2.0) Turbo Ring
2-9
Ring 1/2: 1st Port Status / Ring 1/2: 2nd Port Status
The “Ports Status” indicators show Forwarding for normal transmission, Blocking if this port is connected to
a backup path and the path is blocked, and Link down if there is no connection.
Ring Coupling: Role
Indicates None, Dual Homing, or Ring Coupling.
Ring Coupling: Primary Port
The “Primary Port” indicators show Forwarding for normal transmission, and Link down if there is no
connection.
Ring Coupling: Backup Port Status
The “Backup Port Status” indicators show Forwarding, Blocking, or Link down.
Explanation of “Settings” Items
Ring 1
Setting Description Factory Default
Enabled Enable the Ring 1 settings checked
Disabled Disable the Ring 1 settings
Ring 2*
Setting Description Factory Default
Enabled Enable the Ring 2 settings Not checked
Disabled Disable the Ring 2 settings
NOTE
You should enable both Ring 1 and Ring 2 when the switch interconnects between Ring 1 and Ring
2 in the
Dual
-Ring architecture.
Set as Master (Ring 1/2)
Setting Description Factory Default
Enabled Select this switch as Master Not checked
Disabled Do not select this switch as Master
Redundant Ports (Ring 1/2)
Setting Description Factory Default
1st Port Select any port of this switch to be one of the redundant ports.
Ring 1: G2
Ring 2: G1
2nd Port Select any port of this switch to be one of the redundant ports.
Ring 1: G3
Ring 2: 7
Ring Coupling: Enable
Setting Description Factory Default
Enable Select this switch as Coupler
Not checked
Disable Do not select this switch as Coupler
Ring Coupling: Coupling Mode
Setting Description Factory Default
Dual Homing Select this item to change to the Dual Homing configuration
page
Primary port: 1
Backup port: 2
Ring Coupling
(backup)
Select this item to change to the Ring Coupling (backup)
configuration page
Port 1
Ring Coupling
(primary)
Select this item to change to the Ring Coupling (primary)
configuration page
Port 1
