Managed Ethernet Switch Redundancy Protocol (UI 2.0) STP/RSTP/MSTP

5-11

Enable

Setting Description Factory Default

Enable/Disable Select to enable the port as a node on the Multiple

Spanning Tree topology.

Disabled

Priority

Setting Description Factory Default

Numerical value selected by

user

Increase this port’s priority as a node on the Multiple

Spanning Tree topology by entering a lower number.

128

Cost

Setting Description Factory Default

Numerical value input by user Input a higher cost to indicate that this port is less

suitable as a node for the Multiple Spanning Tree

topology. Use the default value (0) to use port speed

in the auto port cost.

Oper Cost

It indicates the cost of the path to the other bridge from this transmitting bridge at the specified port.

Edge

Setting Description Factory Default

Enable/Disable Select to enable the port as the edge port for the

Multiple Spanning Tree topology.

Disabled

State

Indicates the current Multiple Spanning Tree status of this port. The “Blocking” status indicates the

transmission is blocked; the “Learning” status indicates the MAC address of the device is being recorded in the

MAC table, and the “Forwarding” status indicates normal transmission.

Role

Indicates the current port role status.

Setting Port Role Status Factory Default

Port Role Backup

Alternate port

Root port

Designated port

Disable

None
