LED Indicators
The front panel of the EDS-P308 Series contains several LED indicators.
The function of each LED is described in the table below.
LED
Color
State
Description
PWR1 AMBER
On
Power is being supplied to power input
PWR1
Off
Power is
not
being supplied to power
input PWR1
PWR2 AMBER
On
Power is being supplied to power input
PWR2
Off
Power is not being supplied to power
input PWR2
FAULT RED
On
When the corresponding PORT alarm is
enabled, and the port’s link is inactive.
Off
When the corresponding PORT alarm is
enabled and the port’s link is active, or
when the corresponding PORT alarm is
disabled.
10M GREEN
On
TP port’s 10 Mbps link is active
Blinking
Data is being transmitted at 10 Mbps
Off
TP Port’s 10 Mbps link is inactive
100M GREEN
On
TP port’s 100 Mbps link is active
Blinking
Data is being transmitted at 100 Mbps
Off
100BaseTX Port’s link is inactive
FX GREEN
On
FX port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100 Mbps.
Off
100BaseFX Port’s link is inactive.
PoE AMBER
On
Power is being supplied to Powered Device
(PD)
Off
Power is not being supplied to Powered
Device (PD)
Package Checklist for SPL-24
The Moxa SPL-24 is shipped with the following items. If any of these items
is missing or damaged, please contact your customer service
representative for assistance.
• Moxa PoE Splitter, SPL-24
• Hardware Installation Guide
• Moxa Product Warranty Statement
Features of SPL-24
High Performance Network Switching Technology
• IEEE802.3af compliance
• Power/data split from PoE lines using either spare-pairs or data pairs
• Support for up to 12.95 W at 24 VDC
• Support for up to 15.4 watts per PoE port
• Short circuit protection
• Auto disconnection for over voltage or under voltage
• Power consumption detection and classification
