- 13 -
Rugged Design
• Operating temperature range from 0 to 60°C, or extended operating
temperature from -40 to 75°C for “-T” models
• IP30, plastic case
• DIN-Rail or panel mounting ability
Specifications of SPL-24
Technology
Standards
IEEE802.3af
Interface
RJ45 Ports
10/100BaseT(X) for PoE IN, and
10/100BaseT(X) for DATA OUT
LED Indicators
Power
Power
Input voltage
44 to 75 VDC
Output voltage
24 VDC
Output current
0.54 A @ 24V
Output Power
12.95 W (@ 24VDC)
Connection
Removable “3-pin” Terminal Block for output
Overload current Protection
400 mA (@48 VDC input)
Efficiency
85% (at 25°C, full-loaded)
Mechanical
Casing
IP30 protection, plastic case
Dimensions
25 × 109 × 88 mm (W × H × D)
Weight
95 g
Installation
DIN-Rail, Wall Mounting
Environmental
Operating Temperature
0 to 60°C (32 to 140°F)
-40 to 75°C (-40 to 167°F) for -T models
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity
5 to 95% (non-condensing)
Regulatory Approvals
Safety
Pending: UL60950, UL 508, CSA C22.2 No.
60950, EN60950 (pending)
Hazardous Location UL/cUL Class I, Division 2, Groups A, B, C
and D (pending)
ATEX Class I, Zone 2, EEx nC IIC (pending)
EMI
FCC Part 15, CISPR (EN55022) class A
EMS
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
Shock
IEC60068-2-27
Freefall
IEC60068-2-32
Vibration
IEC60068-2-6
WARRANTY
5 years
