Moxa WAC-1001 [22/56] Wlan security settings

WAC-1001 Web Console Configureation

3-9

WLAN Security Settings

By enabling the 802.11X, you can use the Extensible Authentication Protocol (EAP), a framework

authentication protocol used by 802.1X, to provide network authentication. Such enterprise-level security

modes require a back-end Remote Authentication Dial-In User Service (RADIUS) server if IEEE 802.1X

functionality is enabled in WPA/WPA2. The IEEE 802.1X protocol also provides the ability possibility to carry out

efficient connection authentication for a large-scale network. It is not necessary to exchange keys or

passphrases.

When you enable EAP, the WPA/WPA2-enterprise wireless security functions of the managed APs will be

disabled. The WAC-1001 will then act as an EAP proxy or relay to support WAP/WPA2-enterprise wireless

security.

802.1X/ EAP

Setting Description Factory Default

Enable/Disable Enables EAP proxy/relay support. The wireless security

functions of the managed APs will be disabled.

Disable

Primary/ Secondary RADIUS server IP

Setting Description Factory Default

The IP address of the

RADIUS server

Specifies the delegated RADIUS server for EAP None

Primary/ Secondary RADIUS server port

Setting Description Factory Default

Port number Specifies the port number of the delegated RADIUS server 1812

Primary/ Secondary RADIUS shared key

Setting Description Factory Default

Max. 31 characters The secret key shared between the AP and RADIUS server None

NOTE

The wireless security settings of all the APs that are deployed in the same

roaming domain

must be consistent

and homogeneous. Different security settings in same

-grouped APs may cause Turbo Roaming

failures. Refer

to the

AWK-3121/4121-RS manual for detailed information about the Wireless Setting.
