DA-710 Series Linux Introduction
1-7
threading
mysql-common 5.0.51a-
24+lenny2
MySQL database common files
ncurses-base 5.7+20081213-1 basic terminal type definitions
ncurses-bin 5.7+20081213-1 terminal-related programs and man pages
ncurses-term 5.7+20081213-1 additional terminal type definitions
net-tools 1.60-22 The NET-3 networking toolkit
netbase 4.34 Basic TCP/IP networking system
netcat-traditional 1.10-38 TCP/IP swiss army knife
nfs-common 1:1.1.2-6lenny1 NFS support files common to client and server
ntpdate 1:4.2.4p4+dfsg-8len
ny2
client for setting system time from NTP servers
openbsd-inetd 0.20080125-2 The OpenBSD Internet Superserver
openssh-blacklist 0.4.1 list of default blacklisted OpenSSH RSA and DSA keys
openssh-blacklist-extr
a
0.4.1 list of non-default blacklisted OpenSSH RSA and DSA keys
openssh-client
1:5.1p1-5
secure shell client, an rlogin/rsh/rcp replacement
openssh-server 1:5.1p1-5 secure shell server, an rshd replacement
openssl 0.9.8g-15+lenny5 Secure Socket Layer (SSL) binary and related cryptographic
too
openssl-blacklist 0.4.2 list of blacklisted OpenSSL RSA keys
openvpn 2.1~rc11-1 virtual private network daemon
openvpn-blacklist 0.3 list of blacklisted OpenVPN RSA shared keys
passwd 1:4.1.1-6 change and administer password and group data
pciutils 1:3.0.0-6 Linux PCI Utilities
perl 5.10.0-19lenny2 Larry Wall's Practical Extraction and Report Language
perl-base 5.10.0-19lenny2 minimal Perl system
perl-modules 5.10.0-19lenny2 Core Perl modules
php5-common 5.2.6.dfsg.1-1+lenn
y3
Common files for packages built from the php5 source
portmap 6.0-9 RPC port mapper
ppp 2.4.4rel-10.1 Point-to-Point Protocol (PPP) - daemon
pppconfig 2.3.18 A text menu based utility for configuring ppp
pppoe 3.8-3 PPP over Ethernet driver
pppoeconf 1.18 configures PPPoE/ADSL connections
procps 1:3.2.7-11 /proc file system utilities
proftpd
1.3.1-17lenny2
versatile, virtual-hosting FTP daemon
proftpd-basic 1.3.1-17lenny2 versatile, virtual-hosting FTP daemon - binaries
proftpd-mod-ldap 1.3.1-17lenny2 versatile, virtual-hosting FTP daemon - LDAP module
proftpd-mod-mysql 1.3.1-17lenny2 versatile, virtual-hosting FTP daemon - MySQL module
proftpd-mod-pgsql 1.3.1-17lenny2 versatile, virtual-hosting FTP daemon - PostgreSQL module
python 2.5.2-3 An interactive high-level object-oriented language (default ve
python-minimal 2.5.2-3 A minimal subset of the Python language (default version)
python2.5 2.5.2-15 An interactive high-level object-oriented language (version 2.
python2.5-minimal 2.5.2-15 A minimal subset of the Python language (version 2.5)
readline-common 5.2-3.1 GNU readline and history libraries, common files
rsyslog 3.18.6-4 enhanced multi-threaded syslogd
sed 4.1.5-6 The GNU sed stream editor
snmp 5.4.1~dfsg-12 SNMP (Simple Network Management Protocol) applications
snmpd 5.4.1~dfsg-12 SNMP (Simple Network Management Protocol) agents
ssh 1:5.1p1-5 secure shell client and server (metapackage)
ssl-cert 1.0.23 simple debconf wrapper for OpenSSL
sysv-rc 2.86.ds1-61 System-V-like runlevel change mechanism
sysvinit 2.86.ds1-61 System-V-like init utilities
