DA-710 Series Linux Introduction
1-6
libslang2 2.1.3-3 The S-Lang programming library - runtime version
libsnmp-base 5.4.1~dfsg-12 SNMP (Simple Network Management Protocol) MIBs and
documentati
libsnmp15 5.4.1~dfsg-12 SNMP (Simple Network Management Protocol) library
libsqlite3-0 3.5.9-6 SQLite 3 shared library
libss2 1.41.3-1 command-line interface parsing library
libssl0.9.8 0.9.8g-15+lenny1 SSL shared libraries
libstdc++6 4.3.2-1.1 The GNU Standard C++ Library v3
libstdc++6-4.3-dev 4.3.2-1.1 The GNU Standard C++ Library v3 (development files)
libsysfs2 2.1.0-5 interface library to sysfs
libtasn1-3
1.4-1
Manage ASN.1 structures (runtime)
libtext-charwidth-per 0.04-5+b1 get display widths of characters on the terminal
libtext-iconv-perl 1.7-1+b1 converts between character sets in Perl
libtext-wrapi18n-perl 0.06-6 internationalized substitute of Text::Wrap
libusb-0.1-4 2:0.1.12-13 userspace USB programming library
libuuid1 1.41.3-1 universally unique id library
libvolume-id0 0.125-7+lenny1 libvolume_id shared library
libwrap0 7.6.q-16 Wietse Venema's TCP wrappers library
libx11-6 2:1.1.5-2 X11 client-side library
libx11-data 2:1.1.5-2 X11 client-side library
libxapian15 1.0.7-4 Search engine library
libxau6 1:1.0.3-3 X11 authorisation library
libxcb-xlib0 1.1-1.2 X C Binding, Xlib/XCB interface library
libxcb1 1.1-1.2 X C Binding
libxdmcp6 1:1.0.2-3 X11 Display Manager Control Protocol library
libxext6 2:1.0.4-1 X11 miscellaneous extension library
libxml2 2.6.32.dfsg-5 GNOME XML library
libxmuu1 2:1.0.4-1 X11 miscellaneous micro-utility library
linux-image-2.6-686 2.6.26+17+lenny1 Linux 2.6 image on PPro/Celeron/P/PI/P4
linux-image-2.6.26-2-
686
2.6.26-17lenny1 Linux 2.6.26 image on PPro/Celeron/P/PI/P4
linux-libc-dev 2.6.26-19 Linux support headers for userspace development
locales 2.7-18 GNU C Library: National Language (locale) data [support]
lockfile-progs 0.1.11-0.1 Programs for locking and unlocking files and mailboxes
login 1:4.1.1-6 system login tools
logrotate
3.7.1-5
Log rotation utility
lrzsz 0.12.21-4.1 Tools for zmodem/xmodem/ymodem file transfer
lsb-base 3.2-20 Linux Standard Base 3.2 init script functionality
lzma 4.43-14 Compression method of 7z format in 7-Zip program
m4 1.4.11-1 a macro processing language
make 3.81-5 The GNU version of the "make" utility.
makedev 2.3.1-88 creates device files in /dev
man-db 2.5.2-4 on-line manual pager
manpages 3.05-1 Manual pages about using a GNU/Linux system
mawk 1.3.3-11.1 a pattern scanning and text processing language
mime-support 3.44-1 MIME files 'mime.types' & 'mailcap', and support programs
minicom 2.3-1 friendly menu driven serial communication program
mktemp 1.5-9 tool for creating temporary files
mlocate 0.21.1-1 quickly find files on the filesystem based on their name
modconf 0.3.9 Device Driver Configuration
module-init-tools 3.4-1 tools for managing Linux kernel modules
mount 2.13.1.1-1 Tools for mounting and manipulating filesystems
mutt 1.5.18-6 text-based mailreader supporting MIME, GPG, PGP and
