DA-710 Series Linux Software Configuration
2-7
Enabling and Disabling Daemons
The following daemons are enabled when the DA-710-LX boots up for the first time.
•
snmpd
SNMP Agent
Daemon
•
elnetd
Telnet Server/Client
Daemon
•
inetd
Internet Daemons
•
ftpd
FTP Server/Client
Daemon
•
sshd
Secure Shell Server
Daemon
•
httpd
Apache WWW Server
Daemon
Type the command ps –ef to list all processes currently running.
MOXA:~# ps -ef
PID Uid VmSize Stat Command
1 root 1296 S init
2 root S [keventd]
3 root S [ksoftirqd_CPU0]
4 root S [kswapd]
5 root S [bdflush]
6 root S [kupdated]
7 root S [mtdblockd]
8 root S [khubd]
10 root S [jffs2_gcd_mtd3]
32 root D [ixp425_csr]
38 root 1256 S stdef
47 root 1368 S /usr/sbin/inetd
53 root 4464 S /usr/sbin/httpd
63 nobody 4480 S /usr/sbin/httpd
64 nobody 4480 S /usr/sbin/httpd
65 nobody 4480 S /usr/sbin/httpd
66 nobody 4480 S /usr/sbin/httpd
67 nobody 4480 S /usr/sbin/httpd
92 bin 1460 S /sbin/portmap
105 root 1556 S /usr/sbin/rpc.statd
109 root 4044 S /usr/sbin/snmpd –s –l /dev/null
111 root 2832 S /usr/sbin/snmptrapd -s
140 root 1364 S /sbin/cardmgr
144 root 1756 S /usr/sbin/rpc.nfsd
146 root 1780 S /usr/sbin/rpc.mountd
153 root 2960 S /usr/sbin/sshd
161 root 1272 S /bin/reportip
162 root 3464 S /bin/massupfirm
163 root 1532 S /sbin/getty 115200 ttyS0
164 root 1532 S /sbin/getty 115200 ttyS1
166 root 3464 S /bin/massupfirm
168 root 3464 S /bin/massupfirm
171 root 3652 S /usr/sbin/sshd
172 root 2200 S -bash
174 root 1592 S ps -ef
MOXA:~#
