DA-710 Series Linux Introduction
1-4
findutils 4.4.0-2 utilities for finding files--find, xargs
ftp 0.17-18 The FTP client
g++ 4:4.3.2-2 The GNU C++ compiler
g++-4.3 4.3.2-1.1 The GNU C++ compiler
gcc 4:4.3.2-2 The GNU C compiler
gcc-4.2-base 4.2.4-6 The GNU Compiler Collection (base package)
gcc-4.3 4.3.2-1.1 The GNU C compiler
gcc-4.3-base 4.3.2-1.1 The GNU Compiler Collection (base package)
gdb 6.8-3 The GNU Debugger
gettext-base 0.17-4 GNU Internationalization utilities for the base system
gnupg 1.4.9-3+lenny1 GNU privacy guard - a free PGP replacement
gpgv 1.4.9-3+lenny1 GNU privacy guard - signature verification tool
grep 2.5.3~dfsg-6 GNU grep, egrep and fgrep
groff-base 1.18.1.1-21 GNU troff text-formatting system (base system components)
grub 0.97-47lenny2 GRand Unified Bootloader (Legacy version)
grub-common
1.96+20080724-16
GRand Unified Bootloader, version 2 (common files)
gzip 1.3.12-6 The GNU compression utility
hostname 2.95 utility to set/show the host name or domain name
ifenslave 2 Attach and detach slave interfaces to a bonding device
ifenslave-2.6 1.1.0-10 Attach and detach slave interfaces to a bonding device
ifupdown 0.6.8+nmu1 high level tools to configure network interfaces
initramfs-tools 0.92o tools for generating an initramfs
initscripts 2.86.ds1-61 Scripts for initializing and shutting down the system
iproute 20080725-2 networking and traffic control tools
iptables 1.4.2-6 administration tools for packet filtering and NAT
iputils-ping
3:20071127-1
Tools to test the reachability of network hosts
klibc-utils 1.5.12-2 small utilities built with klibc for early boot
libacl1 2.2.47-2 Access control list shared library
libapache2-mod-php5 5.2.6.dfsg.1-1+lenn
y3
server-side, HTML-embedded scripting language (Apache 2
module
libapr1 1.2.12-5+lenny1 The Apache Portable Runtime Library
libaprutil1 1.2.12+dfsg-8+lenn
y4
The Apache Portable Runtime Utility Library
libattr1 1:2.4.43-2 Extended attribute shared library
libbind9-40 1:9.5.1.dfsg.P3-1 BIND9 Shared Library used by BIND
libblkid1
1.41.3-1
block device id library
libbz2-1.0 1.0.5-1 high-quality block-sorting file compressor library - runtime
libc6 2.7-18 GNU C Library: Shared libraries
libc6-dev 2.7-18 GNU C Library: Development Libraries and Header Files
libc6-i686 2.7-18 GNU C Library: Shared libraries [i686 optimized]
libcap1 1:1.10-14 support for getting/setting POSIX.1e capabilities
libcap2 2.11-2 support for getting/setting POSIX.1e capabilities
libcomerr2 1.41.3-1 common error description library
libconsole 1:0.2.3dbs-65.1 Shared libraries for Linux console and font manipulation
libcwidget3 0.5.12-4 high-level terminal interface library for C++ (runtime files)
libdb4.5 4.5.20-13 Berkeley v4.5 Database Libraries [runtime]
libdb4.6 4.6.21-11 Berkeley v4.6 Database Libraries [runtime]
libdevmapper1.02.1 2:1.02.27-4 The Linux Kernel Device Mapper userspace library
libdns45 1:9.5.1.dfsg.P3-1 DNS Shared Library used by BIND
libedit2 2.11~20080614-1 BSD editline and history libraries
libept0 0.5.22 High-level library for managing Debian package information
libevent1 1.3e-3 An asynchronous event notification library
libexpat1 2.0.1-4 XML parsing C library - runtime library
