DA-710 Series Linux Managing Communications
3-5
Configuring Multiple Serial Ports for Expansion Modules
This section explains how to configure the serial port interface when you have inserted one or more serial
expansion modules on your DA-710’s expansion PCI slots.
In the following case, we will insert three DA-SP08-DB expansion modules. Follow the steps below.
1. Make sure the DA-710 computer is turned off.
2. Insert the three modules on the rear panel of the DA-710.
3. Turn on the DA-710 computer.
4. When the system has rebooted, udev daemon will detect these modules and generate many files under
/dev/ttyMn. (n will range from 0 to 23, 24 ports in total for 3 serial expansion modules)
5. Use the dmesg command to view more information for the serial port configuration. See the following
figure for details.
[ 6.318937] Found MOXA CP-118U series board(BusNo=7,DevNo=12)
[ 6.318947] ACPI: PCI Interrupt 0000:07:0c.0[A] -> GSI 19(level, low) -> IRQ 19
[ 6.318977] ttyM0 - ttyM7 max. baud rate = 921600 bps.
[ 6.319153] mxser_probe[878]5011:4480
[ 6.319155] Found MOXA CP-118U series board(BusNo=7,DevNo=14)
[ 6.319161] ACPI: PCI Interrupt 0000:07:0e.0[A] -> GSI 17(level, low) -> IRQ 17
[ 6.319185] ttyM8 - ttyM15 max. baud rate = 921600 bps.
[ 6.319353] mxser_probe[878]5011:4480
[ 6.319355] Found MOXA CP-118U series board(BusNo=7,DevNo=15)
[ 6.319360] ACPI: PCI Interrupt 0000:07:0f.0[A] -> GSI 16(level, low) -> IRQ 16
[ 6.319385] ttyM16 - ttyM23 max. baud rate = 921600 bps.
However, please note that the order of the PCI device addresses will be decided by the sequence of Module
D, Module C, Module B and Module A. See the following for details.
• 07:0c.0 (Card3) : ttyM0~ttyM7
• 07:0d.0 LAN CARD
• 07:0e.0 (Card2): ttyM8~ttyM15
• 07:0f .0 (Card1): ttyM16~ttyM23
6. You may also use the lspci command to view more information on each PCI slot.
root@Moxa:~#lspci
07:0c.0 Serial controller: Moxa Technologies Co Ltd CP118U (8-port RS-
232/422/485
Smart Universal PCI)
07:0d.0 PCI bridge: Tundra Semiconductor Corp. Device 8100 (rev 01)
07:0e.0 Serial controller: Moxa Technologies Co Ltd CP118U (8-port RS-
232/422/485
Smart Universal PCI)
07:0f.0 Serial controller: Moxa Technologies Co Ltd CP118U (8-port RS-
232/422/485
Smart Universal PCI)
Module A: 07:0f.0
Card1 (8 ports)
Module D: 07:0c.0
Card 3 (8 ports)
Module B: 07:0e.0
Card2 (8 port)
Module C: 07:0d.0
LAN Card
