TC-6110 Series Hardware Introduction
1-4
LED Indicators
LED Name LED Color LED Function
Power
Green Power is on and functioning normally
Off Power is off or power system error
System Ready
Yellow
Logged in to OS, functioning normally
Off Login failure or OS not functioning normally
Tx(P1)
Green Serial port P1 transmitting data
Off Serial port P1 not transmitting data
Rx(P1)
Yellow Serial port P1receving data
Off Serial port P1 not receiving data
LAN(P1-P2)
Green Programmable by users
Yellow Programmable by users
Off Working 100 Mbps Ethernet link
X1-X4
Green Working 1000 Mbps Ethernet link
Off Disconnected or short circuit
Reset Button
The reset button on the TC-6110’s front panel initiates a soft system reboot. Once the system has completed
the reboot the Ready LED will maintain a steady glow.
Features
The TC-6110 computer has the following features:
• Fanless and rugged design for rolling stock applications
• Compliant with EN 50121-4 and essential sections of EN 50155
• Protective conformal coating to prevent moisture, dust, and corrosion
• 3U high compact design, 24 to 110 VDC isolated wide range power supply
• Modular design for easy storage and peripheral expansion
• Moxa SafeGuard Technology provides:
• Reliable HDD operation at low temperatures
• Independent temperature sensor with custom API
• Independent G-sensor returns system shock/vibration info with custom API
• SNMP-based system configuration and monitoring supported
Hardware Specifications
Computer
CPU:
Intel Atom D525, dual-core 64-bit threaded 1.8 GHz, 1 MB for L2 cache
OS:
Windows Embedded Standard 7 or Linux
Note: The OS is pre
-installed.
System Chipset:
ICH8-M
System Memory:
4 GB capacity, 2 GB pre-installed: 2 slots of 2 GB DDR3-1066 204 pin SO-DIMM SDRAM
USB:
USB 2.0 hosts x 3 (Type A connectors x 2, supporting system boot up; D-coded, 5-pin, female M12
connectors x 1)
Storage
Built
-in: 8 GB onboard industrial CompactFlash card for operating system storage
HDD Support:
2 removable TC-SATA-T storage trays, for 2.5-
inch SSD or HDD storage drive (with Intelligent
Heating Solution)
