![Moxa MD-226X [37/56] Md 224 hardware manual display control interface](/views2/1200655/page37/bg25.png)
MD-224 Hardware Manual Display Control Interface
5-7
Download the RGB File: D2N Command
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Hex 0x7 0xFF 0x44 0x4C 0x4E 0x1 0x1A Appointed
packet
0xAF
ASCII D 2 N
Here is a sample command to read and return packet zero of the RGB file:
0x07 0xFF 0x44 0x4C 0x4E 0x01 0x1A 0x00 0xFF
Tthis is the ACK packet that is returned, with data packet 0 located in the Data section.
0x06 0xFF 0x44 0x4C 0x4E 0x20 0xFC 0x00 - Data IDCHK
This result shows the actual value of RGB file package 0. The results could be different for different machines.
