MD-224 Hardware Manual Display UART Commands
C-12
MCC Command Syntax and Functionality Details and Values
Example “1”: 07 FF 4D 43 43 02 24 CD 31 01 Available function:
“0” = Normal Display
“1” = Display burn-in Test Pattern
Reset Factory Default Send only: 07 FF 4D 43 43 01 25 CE 31 Available response status:
“0” = fail
“1” = successful
Menu Button Send only: 07 FF 4D 43 43 01 25 F7 08 Physical Button press equivalent
Down Button Send only: 07 FF 4D 43 43 01 25 FA 05 Physical Button press equivalent
Up Button Send only: 07 FF 4D 43 43 01 25 FB 04 Physical Button press equivalent
ECDIS Button Send only: 07 FF 4D 43 43 01 25 FC 03 Physical Button press equivalent
INFO Button Send only: 07 FF 4D 43 43 01 25 FD 02 Physical Button press equivalent
