MD-224 Hardware Manual Display UART Commands
C-9
NOTE
Due to firmware revisions, some commands listed below will not be
supported by earlier units.
MCC Command Syntax and Functionality Details and Values
Brightness Control Syntax: 07 FF 4D 43 43 03 23 81 xx yy zz
Function Examples:
Example "255":07 FF 4D 43 43 03 23 81 46 46 F2
Query "?": 07 FF 4D 43 43 02 24 81 3F 3F
Reset "R": 07 FF 4D 43 43 02 24 81 52 2C
Reset "r": 07 FF 4D 43 43 02 24 81 72 0C
Increase "+": 07 FF 4D 43 43 02 24 81 2B 53
Decrease "-": 07 FF 4D 43 43 02 24 81 2D 51
Where xx = "0" to "F"
Where yy = "0" to "F"
Where zz = Calculated Checksum
Max Range: "0" "0" to "F" "F"
Default: "A" "0"（160）
Contrast Control Syntax: 07 FF 4D 43 43 04 22 82 ww xx yy zz
Function Examples:
Example "A00": 07 FF 4D 43 43 04 22 82 41 30 30 DC
Example "a00": 07 FF 4D 43 43 04 22 82 61 30 30 BC
Query "?": 07 FF 4D 43 43 02 24 82 3F 3E
Reset "R": 07 FF 4D 43 43 02 24 82 52 2B
Reset "r": 07 FF 4D 43 43 02 24 82 72 0B
Increase "+": 07 FF 4D 43 43 02 24 82 2B 52
Decrease "-": 07 FF 4D 43 43 02 24 82 2D 50
Where ww = "a" to "A"
Where xx = "0" to "6"
Where yy = "0" to "F"
Where zz = Calculated Checksum
Max Range: "0" "0" to "6" "4"
Default: "0" "0"
Manual Clock Control Syntax: 07 FF 4D 43 43 02 24 85 xx zz
Function Examples:
Increase "+": 07 FF 4D 43 43 02 24 85 2B 4F
Decrease "-": 07 FF 4D 43 43 02 24 85 2D 4D
For VGA Mode only
Image Horizontal Position Syntax: 07 FF 4D 43 43 02 24 86 xx zz
Function Examples:
Increase "+": 07 FF 4D 43 43 02 24 86 2B 4E
Decrease "-": 07 FF 4D 43 43 02 24 86 2D 4C
For VGA Mode only
Image Vertical Position Syntax: 07 FF 4D 43 43 02 24 87 xx zz
Function Examples:
Increase "+": 07 FF 4D 43 43 02 24 87 2B 4D
Decrease "-": 07 FF 4D 43 43 02 24 87 2D 4B
For VGA Mode only
Auto Source Syntax: 07 FF 4D 43 43 02 24 88 xx zz
Function Examples:
Example "1": 07 FF 4D 43 43 02 24 88 31 46
Query "?": 07 FF 4D 43 43 02 24 88 3F 38
Reset "R": 07 FF 4D 43 43 02 24 88 52 25
Reset "r": 07 FF 4D 43 43 02 24 88 72 05
Where xx = “0” to “1”
Where zz = Calculated Checksum
Available function:
“0” = Disble
“1” = Enable
OSD Lock Mode Syntax: 07 FF 4D 43 43 02 24 8D xx zz
Function Examples:
Example "1": 07 FF 4D 43 43 02 24 8D 31 41
Query "?": 07 FF 4D 43 43 02 24 8D 3F 33
Reset "R": 07 FF 4D 43 43 02 24 8D 52 20
Reset "r": 07 FF 4D 43 43 02 24 8D 72 00
Set "999": 07 FF 4D 43 43 05 21 8D 53 39 39 39 74
Where xx = “0” to “1”
Where zz = Calculated Checksum
Available function:
“0” = Normal（default）
“1” = Menu Protection
“S” = Set password（default is
“000”）
Auto Adjustment Syntax: 07 FF 4D 43 43 02 24 8F xx zz
Function Examples:
Example "1": 07 FF 4D 43 43 02 24 8F 31 3F
Query "?": 07 FF 4D 43 43 02 24 8F 3F 31
For VGA Mode only
Where xx = “0” to “1”
Where zz = Calculated Checksum
Available function:
“0” = Off （default）
“1” = On （do auto adjustment）
Note: Auto adjustment will be
executed when previous auto
adjusting is finished.
