MD-224 Hardware Manual Display UART Commands
C-5
GMB (Glass Display Control - Minimum Brightness)
This command sets the minimum value that can be used to the brightness of touch keypad LED. Be sure to
configure this setting to a value that will ensure that the LED indicators are still visible if they are adjusted down
to this minimum value. The range starts from 0x00 to 0x31 (0% - 100%). LEN=one date byte.
Examples:
Command to set 30% Brightness.
0x07 0xFF 0x47 0x4D 0x42 0x01 0x22 0x10 0xEF
POT (Potentiometer Control)
The BR+/BR- key default value is Enable. Users can send this command to disable/enable the BR+/BR- key.
If the data and data checksum are incorrect, the reply data field is the current control status. LEN=one data
byte.
0x00 Brightness +/Brightness - Key Disable
0xFF Brightness +/Brightness - Key Enable
Examples:
Disable the BR+/BR- Key.
0x07 0xFF 0x50 0x4F 0x54 0x01 0x05 0x00 0xFF
ACK
0x06 0xFF 0x50 0x4F 0x54 0x01 0x06 0x00 0xFF
SWI (Scalar Firmware Version Query)
This command queries the scalar firmware version.
Examples:
Query Scalar Firmware Version
0x07
0xFF
0x53
0x57
0x49
0x00
0x06
SWK (Touch Keypad Firmware Version Query)
This command queries the touch keypad firmware version.
Examples:
Query Touch Keypad Firmware Version
0x07 0xFF 0x53 0x57 0x4B 0x00 0x04
ADF (AC Input Power Detect Function)
This default value of this function is OFF. If the MD-224 supports an AC power input, you can turn on this
function to detect the AC input power when the MD-224 has connected to the AC power. LEN=one data byte.
0x00 AC Input Power Detect is OFF
0xFF AC Input Power Detect is ON
Examples:
Set “OFF”.
0x07 0xFF 0x41 0x44 0x46 0x01 0x2D 0x00 0xFF
ACK
0x06 0xFF 0x41 0x44 0x46 0x01 0x2E 0x00 0xFF
