D. Network Port Numbers
ioLogik E1200 Network Port Usage
Port Type Usage
68 UDP BOOTP/DHCP
69 UDP Export/import configuration file
80 TCP Web console service
161 UDP SNMP Agent
502 TCP Modbus/TCP communication
2222 UDP EtherNet/IP implicit message
4800 UDP Auto search
9020 TCP Peer-to-peer (default)
9200 TCP ioLogik 2500’s expansion
10124 TCP Configuration port (ioSearch)
44818 TCP EtherNet/IP explicit message
