ioLogik R1200 Series Modbus Mapping
A-17
Reference Address Data Type Description
3:under-ranged
30994 0x03E1 1 Word CH1 AI status, 0: normal, 1:burnout, 2: over-ranged,
3:under-ranged
30995 0x03E2 1 Word CH2 AI status, 0: normal, 1:burnout, 2: over-ranged,
3:under-ranged
30996 0x03E3 1 Word CH3 AI status, 0: normal, 1:burnout, 2: over-ranged,
3:under-ranged
30997 0x03E4 1 Word CH4 AI status, 0: normal, 1:burnout, 2: over-ranged,
3:under-ranged
30998 0x03E5 1 Word CH5 AI status, 0: normal, 1:burnout, 2: over-ranged,
3:under-ranged
30999 0x03E6 1 Word CH6 AI status, 0: normal, 1:burnout, 2: over-ranged,
3:under-ranged
31000 0x03E7 1 Word CH7 AI status, 0: normal, 1:burnout, 2: over-ranged,
3:under-ranged
4xxxx Read/Write Registers (Functions 3, 6, 16)
Reference Address Data Type Description
40705 0x02C0 1 Word CH0 AI range, 0: 0-10V, 1:0-20 mA, 2: 4-20 mA burnout
40706 0x02C1 1 Word CH1 AI range, 0: 0-10V, 1:0-20 mA, 2: 4-20 mA burnout
40707 0x02C2 1 Word CH2 AI range, 0: 0-10V, 1:0-20 mA, 2: 4-20 mA burnout
40708 0x02C3 1 Word CH3 AI range, 0: 0-10V, 1:0-20 mA, 2: 4-20 mA burnout
40709 0x02C4 1 Word CH4 AI range, 0: 0-10V, 1:0-20 mA, 2: 4-20 mA burnout
40710 0x02C5 1 Word CH5 AI range, 0: 0-10V, 1:0-20 mA, 2: 4-20 mA burnout
40711 0x02C6 1 Word CH6 AI range, 0: 0-10V, 1:0-20 mA, 2: 4-20 mA burnout
40712 0x02C7 1 Word CH7 AI range, 0: 0-10V, 1:0-20 mA, 2: 4-20 mA burnout
40737 0x02E0 2 Word CH0 AI burnout value (float)
40739 0x02E2 2 Word CH1 AI burnout value (float)
40741 0x02E4 2 Word CH2 AI burnout value (float)
40743 0x02E6 2 Word CH3 AI burnout value (float)
40745 0x02E8 2 Word CH4 AI burnout value (float)
40747 0x02EA 2 Word CH5 AI burnout value (float)
40749 0x02EC 2 Word CH6 AI burnout value (float)
40751 0x02EE 2 Word CH7 AI burnout value (float)
