ioLogik R1200 Series Overview
1-2
Introduction
The ioLogik R1200 is an industrial grade, wide-temperature serial remote I/O device equipped with dual
RS-485 ports that allow users to select between two RS-485 serial ports or switch to a built-in repeater.
Applications such as factory automation, security and surveillance systems, and tunnel monitoring can use the
RS-485 serial line to set up multi-drop device configurations through serial cables. Furthermore, a technician
with no serial background can upload device configurations and firmware via USB at the field site without
bringing a PC to the field site. The ioLogik R1200 lets you easily build an industrial grade, long distance
communication system with standard PC hardware, and extends the communication distance by 4,000 ft.
(1,200 m).
Product Features
• Upload and install device configurations and firmware via USB
• Multi-drop support for device configuration and firmware upgrade via RS-485
• Remote firmware updates via RS-485
• Dual RS-485 ports with built-in repeater
• Wide temperature (-40 to 85°C), 1 kV surge protection, and 3 kV I/O isolation between I/O channels,
networks and power circuits
• Multi-functional I/O support for DI, event counter, DO, and pulse output
• Modbus/RTU support for control by SCADA software, including Wonderware InTouch and GE Intellution
iFix32
• Monitoring and configuration via ioSearch Windows utility
• Hardware detection over RS-485 via ioSearch
Package Checklist
The ioLogik R1200 is shipped with the following items:
• 1 ioLogik R1200 remote I/O product
• Quick Installation Guide (printed)
NOTE
Contact your sales representative if any of the above items are missing or dama
ged.
Product Model Information
Ordering Information
ioLogik R1210 RS-485 remote I/O, 16 DIs, -10 to 75°C operating temperature.
ioLogik R1210-T RS-485 remote I/O, 16 DIs, -40 to 85°C operating temperature.
ioLogik R1212 RS-485 remote I/O, 8 DIs, 8 DIOs, -10 to 75°C operating temperature.
ioLogik R1212-T RS-485 remote I/O, 8 DIs, 8 DIOs, -40 to 85°C operating temperature.
ioLogik R1214 RS-485 remote I/O, 6 DIs, 6 Relays, -10 to 75°C operating temperature.
ioLogik R1214-T RS-485 remote I/O, 6 DIs, 6 Relays, -40 to 85°C operating temperature.
ioLogik R1240 RS-485 remote I/O, 8 AIs, -10 to 75°C operating temperature.
ioLogik R1240-T RS-485 remote I/O, 8 AIs, -40 to 85°C operating temperature.
ioLogik R1241 RS-485 remote I/O, 4 AOs, -10 to 75°C operating temperature.
ioLogik R1241-T RS-485 remote I/O, 4 AOs, -40 to 85°C operating temperature.
