Click&Go V2 Getting Started
2-3
Optional Liquid Crystal Display Module (LCM)
The ioLogik E2000 series supports an optional hot-pluggable Liquid Crystal Module (LCM) for field management
and configuration. The LCM can display network and I/O settings such as digital input mode and value. The
ioLogik E2000 series’ IP address and netmask can also be configured using the LCM, and one LCM can be used
to maintain and configure multiple ioLogik products.
Optional Accessories
• LDP1602 ioLogik LCM (Liquid Crystal Display Module)
Adding More I/O Channels
A cost-effective way to add more I/O channels to your Ethernet-based ioLogik E2000 series is to attach an
appropriate RS-485 ioLogik R2000 series I/O. However, it is important to remember that Click&Go local control
logic does NOT apply to the expanded channels from an external ioLogik.
ATTENTION
Extension I/O channels from another
ioLogik R2000 will NOT be a part of Click&Go logic, those additional
channels can only be polled by a remote host computer.
Connecting the I/O Device
The ioLogik series is equipped with multiple input and multiple output channels. These channels are designed
to offer greater flexibility for connecting I/O devices. The sensor type determines your wiring approach so
please refer to the specific I/O model’s user manual for detailed wiring instructions.
ATTENTION
For wiring reference, r
efer to the specific user’s manual for each product.
