Click&Go V2 Click&Go V2 Developing Process
3-16
IF conditions can be specified as follows:
IF Conditions Operators Remark
DI ON, OFF, ON to OFF,
OFF to ON, Change
DI-x represents the number of the channel.
Counter =, >, <, >=, <=, Change Counter-x represents the number of the channel.
Max Counter Value: 4,294,967,295
AI =, >, <, >=, <= AI-x represents the number of the channel.
Max Value: Depends on the analog
Modes or the result of scaling
RTD =, >, <, >=, <= RTD-x represents the number of the channel.
Max Value: Depends on the mode
selection of RTD sensor
TC =, >, <, >=, <= TC-x represents the number of the channel.
Max Value: Depends on the mode
selection of TC sensor
Relay =, >, <, >=, <= CurRelayCNT-x represents the current relay counts
of the channel.
Max Value: 4,294,967,295
Internal Register = Reg-x represents the number of the internal register.
x = 00 to 23 / Trigger Value: 0 to 255
Remote Action Received Action ID: 01 to 24
Source IP Range:
0.0.0.1 to 223.255.255.254
Timer TIMEOUT Timer-x, x = 00 to 23
Max value: 4,294,967,295 seconds
Schedule Time, Range and Recurrence
Host Connection Fail Modbus/TCP Idle Timeout.
Max value: 3,600 seconds
