Click&Go V2 Introduction
1-5
Difference in THEN/ELSE Actions
Click&Go V1.0 Click&Go V1.1 Click&Go V1.x
Input Channel Control
Digital Input Counter Reset
Relay Counter Reset
2
–
SNMP Trap
Active Message
e-Mail
Delay Timer
1
–
–
Timer – –
Internal Register
1
–
Remote Action – –
CGI Command – –
1
Click&Go V1.1 only supports ioLogik E2242 firmware V1.x. The definition of “Internal Register” and the
“Delay Timer” is slightly different from the latest Click&Go V2. The latest Timer covers the function of the
earlier Timer Trigger and the latest Internal Register covers the earlier ones.
2
These specific IF conditions and THEN/ELSE actions are only supported on the ioLogik E2214 Relay Module.
Click&Go Version Check
The best way to verify the current version of the firmware or Click&Go is to run the ioAdmin configuration
utility. After a broadcast search for the ioLogik on the network, ioAdmin displays the information on its “Server
Info.” tab. Refer to the related sections of the product user’s manual for detailed information on software
installation and other operations such as firmware upgrade.
