Moxa MxNVR-IA8 System Configuration
4-24
HTTP Action Setting
Setting Description Default
Server 1, 2, 3, 4 Select the HTTP event server for sending the HTTP action Disable
Blank column The Administrator can customize the message sent to the HTTP
event sever in this column
Blank
CGI Event
The MxNVR can accept five CGI commands, which are sent from external devices, such as ioLogik series
Ethernet I/Os, to be the event alarms.
NOTE The MxNVR only can accept the CGI commands that conform to the MxNVR’s CGI command format.
CGI Event Trigger Actions
Setting Description Default
Enable CGI Event alarm
Enable or disable CGI Event alarm. Disable
Event Select Event 1, 2, 3, 4, 5 Disable
Trigger DO1 alarm Once the CGI Event is triggered, the DO1 alarm will be
activated
Disable
Trigger DO2 alarm Once the CGI Event is triggered, the DO2 alarm will be
activated
Disable
HTTP Action Setting
Setting Description Default
Server 1, 2, 3, 4 Select the HTTP event server for sending the HTTP action Disable
Blank column The administrator can customize the message sent to the HTTP
event sever in this column
Blank
