Moxa MxNVR-IA8 ModBus Address Table
B-2
0x005A R 1 word Fault LED Status
0x0000:No
0x0001:Yes
0x0080 R 1 word DI1
0x0000:Off
0x0001:On
0x0081 R 1 word DI2
0x0000:Off
0x0001:On
0x0082 R 1 word DI3
0x0000:Off
0x0001:On
0x0083 R 1 word DI4
0x0000:Off
0x0001:On
0x0084 R 1 word DI5
0x0000:Off
0x0001:On
0x0085 R 1 word DI6
0x0000:Off
0x0001:On
0x0086 RW 1 word DO1
0x0000:Off
0x0001:On
0x0087 RW 1 word DO2
0x0000:Off
0x0001:On
Recorder
0x0200 R/W 1 word Channel 1 Record Status
0x0000: Off
0x0001: Recording
0x0201 R/W 1 word Channel 2 Record Status
0x0000: Off
0x0001: Recording
0x0202 R/W 1 word Channel 3 Record Status
0x0000: Off
0x0001: Recording
0x0203 R/W 1 word Channel 4 Record Status
0x0000: Off
0x0001: Recording
0x0204 R/W 1 word Channel 5 Record Status
0x0000: Off
0x0001: Recording
0x0205 R/W 1 word Channel 6 Record Status
0x0000: Off
0x0001: Recording
0x0206 R/W 1 word Channel 7 Record Status
0x0000: Off
0x0001: Recording
