10
䡲 Loosen the blockage, e.g. with a screwdriver, and tap or
vacuum it out.
(You must fit a dust bag in the vacuum cleaner before
vacuuming it out - see Figure 26)
䡲 Close the bottom flap so that it can be heard snapping
into position.
!
Caution: The micro- and permanent filters must be
cleaned following any operating problem (see Figure
23 and 24).
Using dust bags
If desired, a dust bag may be used instead of the dust
container.
Figure
䡲 Open the dust bag compartment lid.
䡲 Remove the dust container and insert a dust bag.
䡲 Close the vacuum cleaner lid.
You have bought an extremely powerful device.
The highest suction setting is therefore only recommended
for heavily soiled, short-pile carpets and hard floors.
The required suction power can be selected by adjusting
the suction regulator (see Figure 9).
䡲 Low suction range:
For vacuuming delicate fabrics, e.g. curtains.
䡲 Middle suction range:
For daily vacuuming of lightly soiled floors.
䡲 High suction range:
For vacuuming durable floor coverings, hard floors and
for heavily soiled surfaces.
Replacing the dust bag
Figure
a) If the dust bag change indicator is completely yellow
when the floor tool is lifted from the floor and the highest
suction power is selected, the dust bag needs changing.
Even if the dust bag is not full, it may still need changing,
due to the type of dust which has been vacuumed.
First check that the nozzle, suction pipe and flexible tube
are not blocked, as this would also lead to dust bag
change indicator being triggered.
b) The handle can easily be detached from the hose to
remove blockages.
Figure
Open the lid by moving the locking lever in the direction
of the arrow.
Figure
a) Seal the dust bag by pulling the sealing strip and then
remove it.
b) Slide the new dust bag into the holder to the stop.
!
Caution: The lid can only be closed when a dust bag has
been inserted.
Cleaning the motor protection filter
The motor protection filter should be cleaned regularly by
knocking out the dirt and rinsing.
Figure
䡲
Open the dust bag compartment lid (see Figure 19).
30
29
28
27*
26
䡲
Pull out the motor protection filter in the direction of the
arrow.
䡲
Clean the motor protection filter by tapping it.
䡲
If it is very dirty, the motor protection filter should be
rinsed.
Now leave the filter to dry for at least 24 hours.
䡲
After cleaning, slide the motor protection filter into the
vacuum cleaner and close the dust bag compartment lid.
Replacing the micro-hygiene filter
When should you change the micro-hygiene filter? when
starting a newpack of bags
Figure
䡲
Open the dust bag compartment lid (see Figure 19).
䡲
Release the filter holder by moving the locking lever in
the direction of the arrow.
䡲
Remove the micro-hygiene filter. Insert the new micro-
hygiene filter into the vacuum cleaner.
䡲
Reinsert the filter holder and clip into place.
Replacing the micro active carbon filter
If your vacuum cleaner is equipped with a micro active
carbon filter, this should be replaced every six months.
Figure
䡲
Open the dust bag compartment lid (see Figure 19).
䡲
Release the filter holder by moving the locking lever in
the direction of the arrow.
䡲
Remove the micro active carbon filter.
䡲
Insert the new micro active carbon filter.
䡲
Reinsert the filter holder and clip into place.
Replacing the Hepa filter
If your vacuum cleaner is equipped with a Hepa filter, this
should be replaced once a year.
Figure
䡲
Open the dust bag compartment lid (see Figure 19).
䡲
Release the Hepa filter by moving the locking lever in the
direction of the arrow and remove it from the vacuum
cleaner.
䡲
Insert the new Hepa filter and clip into place.
If you have used the vacuum cleaner for fine dust particles,
clean the motor protection filter and, if necessary, replace
the micro active carbon filter or Hepa filter.
Care
Always switch off the vacuum cleaner and disconnect the
power cord from the mains before cleaning the appliance.
The vacuum cleaner and plastic accessories can be
cleaned with a commercial plastic cleaner.
!
Do not use a scourer, glass-cleaning agent or
multipurpose cleaning product. Never immerse the
vacuum cleaner in water.
The dust compartment can, if necessary, be cleaned with a
second vacuum cleaner or simply wiped with a dry cloth or
dusting brush.
Subject to technical modifications.
