Braun Multiquick 3 J 300 [8/78] Assembling

11 Juice jug lid

12 Foam separator

13 Juice jug

14 Cord storage

15 Cleaning brush

Before using for the first time, wash the detachable

juicer parts (see «Disassembling» and «Cleaning»).

Start lock / Safety system

The appliance can only be switched on when the

juice collector (5) has been inserted and the lid is

securely locked with the clamps (3). When the

clamps are released while the motor is running, the

motor stops within 3 seconds.

Assembling

1. Assemble the juice spout (10a/10b) to the juice

collector (fig. a). Slightly press together the sides

of the juice spout with thumb and forefinger at

the check marks.

2. Put the juice collector (5) on the motor part (1)

(fig. b).

3. Place the filter (6) onto the juice collector and

press it down until it locks on the motor coupling

(fig b).

4. Slide the pulp container (4) to the rear part of the

motor unit until it connects. Be sure it snaps into

place (fig. c).

5. Attach the lid (7) (fig. c). Attach both clamps to

the lugs on the lid and push down firmly until you

hear them snap into place (fig. d).

6. Make sure the juice jug (13) is placed underneath

the juice spout (10) (fig. e). Capacity: 1250 ml.

The juice collector comes with a foam separator

(12) to help keeping the juice almost foam-free. If it

is not required simply remove the foam separator.

Extracting juice

• Important: Use only well ripened fruits otherwise

the filter (6) may be clogged up.

• Before use, always unwind the power cord

completely from the cord storage (14).

• Fruits/vegetables need to be washed if they will

be processed unpeeled.

• Maximum operation time / amount at a time:

15 minutes / 5 kg.

Let appliance cool down sufficiently afterwards.

Type of fruits/

vegetables

Preparation Pro-

cessing

Hard fruits/

vegetables e.g.

apples, pears,

carrots, beets

Remove uneatable

peel

Process seed fruits

with cores

Position II

Leaf vegetables

e.g. cabbage,

spinach or herbs

Roll up leaves

together tightly

before processing

Position II

Soft fruits/

vegetables e.g.

citrus fruits, kiwis

Remove uneatable

peel

Position I

Grapes Cut off main stems

Stone fruits e.g.

plums, peaches

Remove stones

Melons Peel and cut into

pieces to fit the

filling shaft

Tomatoes,

cucumbers,

raspberries

No further

preparation needed

Berries Only suitable in

mixed juices

Position I

Rhubarb, fruits that contain starch

(bananas, mangoes, papayas,

avocados and figs), very hard and

fibrous fruits or vegetables

Not

suitable

• Put fruits or vegetables into the filling shaft (8)

(fig. e).

• Turn the switch (2) to position «I» or «II»:

• Press slightly with the pusher (9) (fig. f). Add

more fruits or vegetables while the motor is

running.

• The amount of juice you extract depends on the

nature of the fruits and vegetables.

• Fruit and vegetable juices contain valuable

vitamins and minerals, which quickly deteriorate

when they come into contact with oxygen or light.

Drink juice fresh – right after it has been

extracted.

Emptying the pulp container and filter

Pulp container (4): As soon as the pulp container

looks full turn off the appliance, unplug it and empty

the pulp container.

Filter (6): If the juice suddenly becomes much

thicker, if larger amounts of pulp get stuck between

filter and lid and/or if you can hear the motor speed

slow down, the filter and juice collector must be

emptied and cleaned (see «Disassembling »).

Empty the pulp container and assemble the appli-

ance again.

Drip stop feature (only model J700/J500)

When the juice spout (10a) is in a tilted position it

functions as a drip stop and collects the dripping

juice:

Turn the appliance off, wait for a few seconds until

the juice only drips from the appliance. Then push

the spout (10a) to the tilted position (fig. g).

Disassembling

1. Switch off the appliance by turning the switch (2)

to position « O » and unplug it (fig. h).

99571518_Juicer_CEE_S6-84.indd 999571518_Juicer_CEE_S6-84.indd 9 20.06.11 14:3620.06.11 14:36
