Loewe Spheros 20 [14/32] Daily use

Loewe Spheros 20 [14/32] Daily use
14
Select the line/function.
Change the function.
You can make additional adjustments in the
Sound menu under “other”:
M
E
Sound menu
Other ...
AVC
Maximum volume
Treble
Bass
Balance
Back
End
50
AV audio sig.
M
E
Sound menu
Sound via
Volume
Headph. vol.
Loudsp. sound
Headph. sound
Other ...
Back
End
Stereo Mono!
Listening mode
Daily Use
To select
menu line ”Sound”.
Call up the Sound menu
To select
menu line.
To change and adjust.
Line: “Sound via”
Select “Hi-fi system” if the TV sound is to be
transmitted over a Hi-fi system. The TV
loudspeakers are turned off. Use a cable to
connect the Hi-fi system to the “AUDIO OUT”
cinch sockets on the rear of the TV set.
Line: “Hi-fi volume”
if “Sound over Hi-fi system” has been selected.
Here you can adjust the volume of the Hi-fi
system using the TV remote control.
Line: ”Listening mode”
Here you can choose between Stereo /
Panorama or Dolby Virtual sound reproduction.
Line: “Volume”
You can adjust the loudspeaker volume using
the right/left arrows on the ring.
Line: “Headphone volume”
Use the right/left arrows on the ring to adjust
the headphone volume.
Line: “Loudspeaker sound”
Here you can select a sound. You can choose
between mono or stereo playback over the Hi-fi
system for stereo programmes. For two-sound
transmissions, you can select the main
language, Sound 1, or the foreign language,
Sound 2.
Line: “Headphone sound”
When receiving a two-sound programme from
the cable network or from a roof-top aerial, you
can select Sound 1 or Sound 2.
Line: “AV Output sound”
If a mono video recorder is connected to the
audio/video connection socket (AV1) of the TV
set, you can select Sound 1 (main sound) or
Sound 2 (foreign language) when receiving a
two-sound programme. You should select
“Sound 1+2” for a stereo video recorder. When
playing back the recording, you can then select
the sound on the recorder.
Line: “AVC”
Use the right/left arrows on the ring to switch
the Automatic Volume Correction on and off. If
“A VC” is switched on, differences in volume
when changing from one channel to another
are reduced.
Line: “Max. volume”
You can limit the adjustable volume of the
loudspeakers. This will prevent children from
setting a volume that is too loud.
Use the right/left arrows on the ring to set a
maximum value for the volume.
Line: “Treble”
Use the right/left arrows on the ring to raise
(values 1 to 12) or lower (values -1 to -12)
treble sounds.
Line: “Bass”
Use the right/left arrows on the ring to raise or
lower (values 1 to 12 or values -1 to -12) bass
sounds.
Line: “Balance”
Use the right/left arrows on the ring to adjust
the balance so that the overall impression of
volume is the same on the right and the left.
Mute on/off
Mute sound, for example when
you want to make a phone call.
To switch the sound back on,
press the button again.
OK
OK
OK
OK
OK
OK
LCD_023_RC4_GB 10.08.2004, 14:08 Uhr14
