1-7ASUS P6-M4A3000E
• Refer to the bundled Quick Installation Guide for installing additional
system components and get assistance from professionals when you
disassemble or assemble the system.
• Refer to the Chapter 3 in this user guide for motherboard details.
1.5 QualiedVendorsLists(QVL)
DDR3-1066MHz capability
DDR3-1333MHz capability
Vendor Part No. Size SS/DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support(Optional)
A* B*
Crucial CT25664BA1067.16FF 2048MB DS Micron 9HF22D9KPT 7 - • •
Crucial CT25672BA1067.18FF 2048MB DS Micron 9GF22D9KPT(ECC) 7 - • •
Elpida EBJ51UD8BAFA-AE-E 512MB SS Elpida J5308BASE-AC-E - - • •
Kingston KVR1066D3N7/1G 1024MB SS Kingston D1288JEKAPGA7U 7 1.5V • •
Micron MT8JTF12864AY-1G1D1 1024MB SS Micron 8ED22D9JNL - - • •
Micron MT16JTF25664AY-1G1D1 2048MB DS Micron 8LD22D9JNL - - • •
Micron MT16JTF25664AZ-1G1F1 2048MB DS Micron 9HF22D9KPT 7 - • •
Micron MT18JSF25672AZ-1G1F1 2048MB DS Micron 9GF22D9KPT(ECC) 7 - • •
SAMSUNG M378B2873EH1-CF8 1024MB SS Samsung
SEC 901 HCF8
K4B1G0846E
- - • •
Vendor Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(Optional)
A* B*
Corsair CM3X1024-1333C9 1024MB SS - - - - • •
Corsair CM3X1024-1333C9DHX 1024MB DS Corsair - - - • •
Crucial CT12872BA1339.9FF 1024MB SS Micron 91F22D9KPT(ECC) 9 - • •
Crucial BL25664BA1336.16SFB1 4096MB(Kit of 2) DS - - 6-6-6-20 1.8V • •
G.SKILL F3-10600CL8D-2GBHK 1024MB SS G.SKILL - - - • •
G.SKILL F3-10666CL9T-6GBNQ 6144MB(Kit of 3) DS - - 9-9-9-24 1.5V~1.6V • •
GEIL GV34GB1333C7DC 2048MB DS - - 7-7-7-24 1.5V • •
Kingmax FLFE85F-B8MF9 2048MB DS Micron 8HD22D9JNM - - • •
Kingston KVR1333D3N9/1G 1024MB SS Hynix H5TQ1G83BFR 9 1.5V • •
Micron MT9JSF 12872AZ-1G4F1 1024MB SS Micron 91F22D9KPT(ECC) 9 - • •
OCZ OCZ3P13332GK 2048MB(Kit of 2) SS - - 7-7-7-20 1.8V • •
SAMSUNG M378B5673DZ1-CH9 2048MB DS Samsung K4B1G0846D-HCH9 - - • •
Transcend TS128MLK64V3U 1024MB SS -
SEC 813HCH9
K4B1G0846D
- - • •
