viii
System package contents
Check your P6-M4A3000E system package for the following items.
If any of the items is damaged or missing, contact your retailer immediately.
Item.description
1. ASUS P6-M4A3000E barebone system with
• ASUS motherboatd
• Power supply unit
• ASUS chassis
2. Cable
• AC power cable
3. Support DVD
4. Quick Installation Guide
