ASUS P6-M4A3000E 4-19
4.5.4 APMConguration
RestoreonACPowerLoss[PowerOff]
When set to [Power Off], the system goes into off state after an AC power loss.
When set to [Power On], the system goes on after an AC power loss. When set to
[Last State], the system goes into either off or on state, whatever the system state
was before the AC power loss. Conguration options: [Power Off] [Power On]
[Last State]
Power on From S5 By PME# [Disabled]
Enables or disables PME wake from sleep states.
Conguration options: [Disabled] [Enabled]
Power on From S5 By RTC Alarm [Disabled]
Enables or disables RTC to generate a wake event.
Conguration options: [Disabled] [Enabled]
APM Conguration
Restore on AC Power Loss [Power Off]
Power On From S5 By PME# [Disabled]
Power On From S5 By RTC Alarm [Disabled]
Power Off
Power On
Last State
BIOS SETUP UTILITY
Power
Options
4.5.5 Hardware Monitor
CPU Temperature [xxxºC/xxxºF]
MB Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU / MB
temperature. Select Ignored if you do not wish to display the detected temperature.
CPU Temperature
BIOS SETUP UTILITY
Power
Hardware Monitor
CPU Temperature [43ºC/109ºF]
MB Temperature [31ºC/87.5ºF]
CPU Fan Speed [3515RPM]
Chassis Fan Speed [N/A]
VCORE Voltage [ 1.360V]
3.3V Voltage [ 3.320V]
5V Voltage [ 5.053V]
12V Voltage [12.251V]
Smart Q-Fan Function [Enabled]
