Tp-Link TL-MR6400 [18/142] Chapter 3 quick installation guide

TL-MR6400

300Mbps Wireless N 4G LTE Router

-9-

Chapter 3. Quick Installation Guide

This chapter will show you how to configure the basic functions of your TL-MR6400 using

Quick Setup within minutes.

3.1 3G/4G Router Mode

1. Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC. If

you need instructions as to how to do this, please refer to Appendix B: Configuring the PC.

2. Connect your computer to the router (wired or wireless).

Wired: Connect your computer to the router's LAN port via an Ethernet cable.

Wireless: Connect wirelessly by using the SSID (network name) and Wireless Password

printed on the product label at the bottom of the router.

3. To access the configuration utility, open a web-browser and type the default address

http://tplinkmodem.net in the address field of the browser.

Figure 3-1 Login the router

4. After a moment, a login window will appear, similar to the Figure 3-2. Enter admin for the

User Name and Password, both in lower case letters. Then click the Login button or press

the Enter key.

Figure 3-2 Login Windows



Note:

If the above screen does not pop-up, it means that your Web-browser has been set to a proxy.

Go to Tools > Internet Options > Connections > LAN Settings, in the screen that appears,

cancel the Using Proxy checkbox, and click OK to finish it.
