Tp-Link TL-MR6400 [60/142] Basic security

TL-MR6400

300Mbps Wireless N 4G LTE Router

-51-

Figure 4-41 UPnP Setting

 Current UPnP Status - UPnP can be enabled or disabled by clicking the Enable or

Disable button. This feature is enabled by default.

 Current UPnP Settings List - This table displays the current UPnP information.

 App Description -The description provided by the application in the UPnP request

 External Port - External port, which the router opened for the application.

 Protocol - Shows which type of protocol is opened.

 Internal Port - Internal port, which the router opened for local host.

 IP Address - The UPnP device that is currently accessing the router.

 Status - The port’s status displayed here. “Enabled” means that port is still active.

Otherwise, the port is inactive.

Click the Enable button to enable UPnP.

Click the Disable button to disable UPnP.

Click Refresh to update the Current UPnP Settings List.

4.12 Security

Figure 4-42 The Security menu

There are three submenus under the Security menu as shown in Figure 4-42: Basic Security,

Local Management and Remote Management. Click any of them, and you will be able to

configure the corresponding function.

4.12.1 Basic Security

Choose menu “Security → Basic Security”, you can configure the basic security in the

screen as shown in Figure 4-43.
