Tp-Link TL-MR6400 [49/142] Wireless statistics

TL-MR6400

300Mbps Wireless N 4G LTE Router

-40-

 DTIM Interval - This value determines the interval of the Delivery Traffic Indication

Message (DTIM). You can specify the value between 1-255 Beacon Intervals. The

default value is 1, which indicates the DTIM Interval is the same as Beacon Interval.

 Enable WMM - WMM function can guarantee the packets with high- priority messages

being transmitted preferentially. It is strongly recommended enabled.

 Enable Short GI - This function is recommended for it will increase the data capacity

by reducing the guard interval time.

 Enable AP Isolation - Isolate all connected wireless stations so that wireless stations

cannot access each other through WLAN. This function will be disabled if WDS/Bridge

is enabled.

 Note:

If you are not familiar with the setting items in this page, it's strongly recommended to keep

the provided default values; otherwise it may result in lower wireless network performance.

4.8.5 Wireless Statistics

Choose menu “Wireless → Wireless Statistics”, and then you can see the MAC Address,

Current Status, Received Packets and Sent Packets for each connected wireless station.

Figure 4-26 The router attached wireless stations

 MAC Address - The connected wireless station's MAC address.

 Current Status - The connected wireless station's running status, one of STA-AUTH /

STA-ASSOC / STA-JOINED / WPA / WPA-PSK / WPA2 / WPA2-PSK / AP-UP /

AP-DOWN / Disconnected.

 Received Packets - Packets received by the station.

 Sent Packets - Packets sent by the station.

 Configure - The button is used for loading the item to the Wireless MAC Filtering list.

Deny: if the Wireless MAC Filtering function enable, deny the station to access.

Allow: if the Wireless MAC Filtering function enable, allow the station to access.
