Tp-Link TL-MR6400 [78/142] System routing table

TL-MR6400

300Mbps Wireless N 4G LTE Router

-69-

 Destination Network - The Destination Network is the address of the network or host

that you want to assign to a static route.

 Subnet Mask - The Subnet Mask determines which portion of an IP Address is the

network portion, and which portion is the host portion.

 Gateway - This is the IP Address of the gateway device that allows for contact between

the router and the network or host.

3. Select Enabled or Disabled for this entry on the Status pull-down list.

4. Click the Save button to make the entry take effect.

Other configurations for the entries:

Click the Delete button to delete the entry.

Click the Enable All button to enable all the entries.

Click the Disable All button to disable all the entries.

Click the Delete All button to delete all the entries.

Click the Previous button to view the information in the previous screen, click the Next button

to view the information in the next screen.

4.15.2 System Routing Table

Choose menu “Advanced Routing → System Routing Table”, you can configure the system

routing table in the next screen (shown in Figure 4-67). System routing table views all of the

valid route entries in use.

Figure 4-67 System Routing Table

 Destination Network - The Destination Network is the address of the network or host to

which the static route is assigned.

 Subnet Mask - The Subnet Mask determines which portion of an IP address is the network

portion, and which portion is the host portion.

 Gateway - This is the IP address of the gateway device that allows for contact between the

router and the network or host.
