1. Introduction

Features

 Local and Remote Units connect at distances up to 300 m using Cat 5e

cable

 Deskew Function (CE370 only) – automatically synchronizes the time

delay of RGB signals to compensate for distance

 On Screen Display (CE370 only) – conveniently adjust video quality with

the intuitive OSD menu system

 Adjustable gain control – automatically and manually adjust signal

strength to compensate for distance

 Dual console operation – control your system from both the local and

remote keyboard, monitor, and mouse consoles

 Built-in ASIC for greater reliability and compatibility

 Auto Signal Compensation (ASC) and storage of settings

 RS-232 serial ports – connect to a serial terminal, or serial devices such as

touchscreens and barcode scanners (Baud Rate 115200 bps)

 Audio Enabled – supports stereo speakers and microphone

 Pushbutton operating mode selection (Local Unit only) – select between

Local and Auto operating modes, with the press of a single button

 Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage

15KV) and 2KV surge protection

 High resolution video – up to 1920 x 1200@60Hz (150 m); 1280 x

1024@60Hz (300 m) (CE370)

 Superior Audio – no loss in audio quality at 300 m

 Supports Wide Screen formats*

 Supports VGA, SVGA, SXGA (1280 x 1024), UXGA (1600 x 1200),

WUXGA (1920 x 1200) and multisync monitors; local monitor supports

DDC; DDC2; DDC2B

 Hot pluggable

 Rack mountable

 Easy to install – no software required – connecting cables to the devices is

all it takes

*The EDID data for a widescreen is sent from the local video output port. For

widescreen modes and displays connect the monitor to the local video output

port or use an ATEN EDID emulator.
