Aten CE350 [27/42] Operating modes
![Aten CE350 [27/42] Operating modes](/views2/1211224/page27/bg1b.png)
19
Chapter 3
Operation
Operating Modes
The CE350 / CE370 PS/2 KVM Extender has three operating modes: Local,
Auto, and Remote, as described in the table below:
Note: The default operating mode is Auto.
Mode Description
Local Only the local console has KVM access. The remote console’s
keyboard and mouse input is disabled.
Auto Both the local and remote consoles can have KVM access, but
not at the same time. The console without access has to wait
until the console with access stops inputting data before it can
gain access.
Remote The remote console has KVM access. Remote mode can only
occur when the pushbutton on the Local Unit (CE350L /
CE370L) is set to Auto and the local console is idle. See note
on page 20.
