Aten CE350 [28/42] Mode selection

CE350 / CE370 User Manual

Mode Selection

The Operating Mode Pushbutton, located on the Local Unit’s front panel,

controls the operating mode of the CE350 / CE370 PS/2 KVM Extender

system. Pressing the switch toggles through Local and Auto operating modes.

Note: Remote mode cannot be selected. The remote console can get control

only when the Operating Mode Pushbutton on the CE350L / CE370L is

toggled to Auto and the local console is idle. If the remote console is

then idle for more than five seconds, the local console can gain access.
