1. Introduction
7
CE350R (Remote Unit) Front View
No. Component Description
1 RS-232 Serial Port RS-232 serial devices – such as touchscreens or
barcode scanners – plug into this port.
2 Picture Compensation
Pushbuttons
These pushbuttons adjust the video quality of the
remote console. See CE350R Compensation Control,
page 21 for details.
3 LEDs The CE350R has three LEDs to indicate the operating
status. See page 24.
1
23
