3. Operation

LED Display

The CE350 / CE370 Local and Remote Units have front panel LEDs to indicate

their operating status, as shown in the tables, following:

CE350L / CE370L(Local Units)

LED

Operating Mode

Local Auto

Local

(Green)

 Lights to indicate that the local

console is active (the Remote

LED is off).

 Lights when the local console is

active (the Remote LED is off).

 Turns off when the remote con-

sole is active (the Remote LED

turns on).

 Flashes on and off alternately

with the Remote LED when nei-

ther console is active.

Remote

(Green)

The LED is off

 Lights when the remote console

is active (the Local LED is off).

 Turns off when the local con-

sole is active (the Local LED

turns on).

 Flashes on and off alternately

with the Local LED when nei-

ther console is active.
