CE350 / CE370 User Manual
4
Requirements
Consoles
A VGA, SVGA, SXGA, UXGA, WUXGA, or multisync monitor capable
of the highest resolution you will be using on any computer in the
installation.
Note: If you connect a DDC type monitor to the Local Unit, the monitor
that connects to the Remote Unit must be able to support the highest
video resolution that the DDC monitor can provide
A PS/2 keyboard
A PS/2 mouse
Stereo microphone and stereo speakers (optional)
Computers
The following equipment must be installed on each computer that is to be
connected to the system:
A VGA, SVGA, SXGA, UXGA, WUXGA, or multisync card
A 6-pin Mini-DIN (PS/2) mouse port
A 6-pin Mini-DIN (PS/2) keyboard port
Microphone and speaker ports (optional)
Cables
For optimal signal integrity, and to simplify the layout, we strongly
recommend that you use the high quality custom KVM Cable that is
provided with this package.
Cat 5e cable is required to connect the Local and Remote CE350 / CE370
Units. Cable of a lower standard will result in degrading of the video
signal. We strongly recommend Cat 5e cable.
Maximum Cable Distances
Connection Distance
Computer to Local Unit (CE350L / CE370L) 10 m
Local Unit to Remote Unit (CE350R) 150 m
Local Unit to Remote Unit (CE370RQ) 300 m
Remote Unit (CE350R / CE370RQ) to monitor 20 m
