Aten CE350 [21/42] Installation
![Aten CE350 [21/42] Installation](/views2/1211224/page21/bg15.png)
Chapter 2. Hardware Setup
13
Installation
Grounding
To prevent damage to your installation it is important that all devices are
properly grounded.
1. Use two grounding wires to ground both units by connecting one end of
the wire to the grounding terminal, and the other end of the wire to a
suitable grounded object.
2. Make sure that the computer that the Local Unit connects to and the
monitor that the Remote Unit connects to are properly grounded.
Cat 5e cable
up to 300 m
