Aten CE350 [32/42] Ce350r remote unit

CE350 / CE370 User Manual

CE350R (Remote Unit)

Note: There is a 10-second timeout once a Picture Compensation pushbutton

has been pushed.

LED Indication

Link

(Orange)

 Lights steadily to indicate that the connection to the Local

Unit is ok.

 Flashes when there is a problem with the connection to the

Local Unit and the Remote LED is off.

Remote

(Red)

 Lights steadily when the remote console is active.

 Turns off when the local console is active.

 Flashes to indicate that the system is in Auto mode.

Picture Compensation

(Blue)

 Lights when a Picture Compensation pushbutton has been

pushed (+ or –) and the CE350 is adjusting the video gain.*

 Lights steadily to indicate that the video gain adjustment has

been completed and saved.
