KVM over IP User Manual

154

6. In the Shared Secret field, key in the character string that you want to

use for authentication between the KVM over IP switch and the

RADIUS Server. A minimum of 6 characters is required.

7. On the RADIUS server, Users can be authenticated with any of the

following methods:

 Set the entry for the user as su/xxxx

Where xxxx represents the Username given to the user when the

account was created on the KVM over IP switch.

 Use the same Username on both the RADIUS server and the

KVM over IP switch.

 Use the same Group name on both the RADIUS server and the

KVM over IP switch.

 Use the same Username/Group name on both the RADIUS server

and the KVM over IP switch.

In each case, the user’s access rights are the ones assigned that were

assigned when the User of Group was created on the KVM over IP

switch. (See Adding Users, page 125.)

 LDAP / LDAPS Authentication and Authorization Settings

To allow authentication and authorization for the KVM over IP switch via

LDAP / LDAPS, refer to the information in the table, below:

Item Action

Enable Put a check in the Enable checkbox to allow LDAP / LDAPS

authentication and authorization.

Type Click a radio button to specify whether to use LDAP or LDAPS.

LDAP Server IP

and Port

Select Preferred or Alternate LDAP Server and fill in the IP

address and port number for the LDAP or LDAPS server.

 You can use the IPv4 address, the IPv6 address or the

domain name in the LDAP Server field.

 For LDAP, the default port number is 389; for LDAPS, the

default port number is 636.

Admin DN Consult the LDAP / LDAPS administrator to ascertain the

appropriate entry for this field. For example, the entry might

look like this:

ou=kn8132,dc=aten,dc=com

Admin Name Key in the LDAP administrator’s username.

Password Key in the LDAP administrator’s password.
