Aten KN2124VA [193/287] Chapter 9

175

Chapter 9

Log

Overview

The KVM over IP switch logs all the events that take place on it. To view the

contents of the log, click the Log tab. The device’s Log Information page,

similar to the one below, appears:

Browser GUI

AP GUI
