KVM over IP User Manual
6
Integration with ALTUSEN CC2000 Management software
Manage browser access selection (browser, http, https)
IPv6 capable
Easy-to-Use Interface
Local Console, browser based, and AP GUIs offer a unified multi-
language interface to minimize the user training time and increase
productivity
Multiplatform client support (Windows, Mac OS X, Linux, Sun)
Multi-browser support: Internet Explorer, Chrome, Firefox, Safari, Opera,
Mozilla, Netscape
Browser-based UI in pure Web technology allows administrators to
perform administrative tasks without pre-installed Java software package
required
Launch multiple Virtual Remote Desktops to control multiple servers from
the same login session
Magic Panel
Full-screen or sizable and scalable Virtual Remote Desktop
Panel Array Mode available to both local console and remote access users
Keyboard/Mouse Broadcast – keyboard and mouse inputs can be
duplicated on all the attached servers
Video syncing with the local console – local console monitor’s EDID
information stored on the KVM Adapter Cables for display resolution
optimization
Advanced Security
Remote authentication support: RADIUS, LDAP, LDAPS, and MS Active
Directory
Supports TLS 1.2 encryption and RSA 2048-bit certificates to secure user
logins from browsers
Flexible encryption design allows users to choose any combination of 56-
bit DES, 168-bit 3DES, 256-bit AES, 128-bit RC4, or Random for
independent KB/Mouse, video, and virtual media data encryption
Support for IP/MAC Filter
Configurable user and group permissions for server access and control
