Aten KN2124VA [228/287] Maintenance this function allows the administrator to perform manual maintenance of the database such as erasing specified records before their expiration time is up
![Aten KN2124VA [228/287] Maintenance this function allows the administrator to perform manual maintenance of the database such as erasing specified records before their expiration time is up](/views2/1211310/page228/bge4.png)
KVM over IP User Manual
210
Maintenance:
This function allows the administrator to perform manual maintenance of the
database, such as erasing specified records before their expiration time is up.
End Time Select the time that you want the search to end at.
Pattern Key in the pattern that you are searching for here. The multiple
character wildcard (%) is supported. E.g., h%ds would match
hands and hoods.
Results Lists the events that contained matches for the search.
Search Click this button to start the search.
Print Click this button to print the search results.
Export Click this button to save the search results to file.
Exit Click this button to exit the Log Server.
Item Description
