Appendix
229
When I log in with my Mac
system, the local and
remote mouse pointers do
not sync.
There are two automatic Mouse DynaSync settings: the
default, and Mac2. If mouse synchronization is not
satisfactory with the default, try the Mac 2 setting. See
the Note on page 83 for details.
When I log in with my Sun
system, the local and
remote mouse pointers do
not sync
Automatic Mouse DynaSync sync only supports USB
mice on Windows and Mac (G4 or higher) systems. You
must sync the pointers manually. See Mouse DynaSync
Mode, page 82, and Manual Mouse Synchronization,
page 83, for further details.
After doing the above, refer to Sun / Linux, page 251,
under Additional Mouse Synchronization Procedures for
further steps to take.
When I log in with my Linux
system, the local and
remote mouse pointers do
not sync.
Automatic Mouse DynaSync sync only supports USB
mice on Windows and Mac (G4 or higher) systems. You
must sync the pointers manually. See Mouse DynaSync
Mode, page 82, Manual Mouse Synchronization,
page 83, and Mac and Linux Considerations, page 83,
for further details.
After doing the above, refer to Sun / Linux, page 251,
(under Additional Mouse Synchronization Procedures),
for further steps to take.
Problem Resolution
