Dell p4317q [10/53] Environmental characteristics
![Dell p4317q [10/53] Environmental characteristics](/views2/1218071/page10/bga.png)
10 | About your monitor
Weight without stand
assembly
14.11 kg (31.09 lb)
Weight of stand
assembly
3.3 kg (7.26 lb)
Caution: Any third-party arm or pole purchased separately should support the weight
of the monitor as well as any external brackets and interface plates.
Environmental characteristics
Model P4317Q
Temperature
Operating 0°C to 40°C (32°F to 104°F)
Non-operating Storage
∞
-20°C to 60°C (-4°F to 140°F)
∞
-20°C to 60°C (-4°F to 140°F)
Shipping
Humidity
Operating 10% to 80% (non-condensing)
Non-operating
∞
Storage: 5% to 90% (non-condensing)
∞
Shipping: 5% to 90% (non-condensing)
Altitude
Operating (maximum) 5,000 m (16,400 ft)
Non-operating (maximum) 12,192 m (40,000 ft)
Thermal dissipation
∞
494.9 BTU/hour (maximum)
∞
238.9 BTU/hour (typical)
Power management modes
If you have VESA's DPM™ compliance display card or software installed in your PC,
